hmac_csa_sta.c 文件参考

#include "hmac_csa_sta.h"
#include "hal_ext_if.h"
#include "mac_ie.h"
#include "hmac_main.h"
#include "hmac_chan_mgmt.h"
#include "hmac_mgmt_classifier.h"
#include "hmac_mgmt_bss_comm.h"
#include "oam_ext_if.h"
#include "hmac_beacon.h"
#include "hmac_mgmt_sta.h"
#include "hmac_mgmt_ap.h"
#include "hmac_psm_sta.h"
#include "hmac_power.h"
#include "oal_netbuf_data.h"
#include "hmac_hook.h"
#include "hmac_scan.h"
#include "frw_util_notifier.h"
#include "hmac_feature_interface.h"
#include "hmac_ccpriv.h"
#include "common_log_dbg_rom.h"

hmac_csa_sta.c 的引用(Include)关系图:

宏定义
#define	THIS_FILE_ID   DIAG_FILE_ID_WIFI_HOST_HMAC_CSA_STA_C
#define	THIS_MOD_ID   DIAG_MOD_ID_WIFI_HOST

函数
OSAL_STATIC osal_u32	hmac_sta_csa_fsm_init_event (osal_void *ctx, osal_u16 event, osal_u16 event_data_len, osal_void *event_data)
OSAL_STATIC osal_u32	hmac_sta_csa_fsm_start_event (osal_void *ctx, osal_u16 event, osal_u16 event_data_len, osal_void *event_data)
OSAL_STATIC osal_u32	hmac_sta_csa_fsm_switch_event (osal_void *ctx, osal_u16 event, osal_u16 event_data_len, osal_void *event_data)
OSAL_STATIC osal_u32	hmac_sta_csa_fsm_wait_event (osal_void *ctx, osal_u16 event, osal_u16 event_data_len, osal_void *event_data)
OSAL_STATIC osal_u32	hmac_sta_csa_fsm_invalid_event (osal_void *ctx, osal_u16 event, osal_u16 event_data_len, osal_void *event_data)
OSAL_STATIC osal_void	hmac_sta_csa_fsm_init_entry (osal_void *ctx)
OSAL_STATIC osal_void	hmac_sta_csa_fsm_invalid_entry (osal_void *ctx)
OSAL_STATIC osal_void	hmac_csa_sta_switch_channel (hmac_vap_stru *hmac_vap)
OSAL_STATIC osal_u8	hmac_sta_csa_fsm_get_current_state (hmac_vap_stru *hmac_vap)
OSAL_STATIC osal_bool	hmac_sta_csa_fsm_is_waiting (hmac_vap_stru *hmac_vap)
OSAL_STATIC osal_u32	hmac_sta_csa_fsm_post_event (hmac_vap_stru *hmac_vap, osal_u16 type, osal_u16 datalen, osal_u8 *data)
OSAL_STATIC osal_u32	hmac_trigger_csa_init_scan_params (const hmac_vap_stru *hmac_vap, mac_scan_req_stru *scan_params)
OSAL_STATIC osal_u32	hmac_trigger_csa_scan (hmac_vap_stru *hmac_vap)
OSAL_STATIC osal_bool	hmac_sta_csa_have_vap_is_in_assoc (const hmac_vap_stru *hmac_vap)
OSAL_STATIC osal_void	hmac_sta_csa_fsm_trans_to_state (hmac_vap_stru *hmac_vap, osal_u8 state)
OSAL_STATIC osal_u32	hmac_sta_csa_timeout_fn (osal_void *arg)
OSAL_STATIC osal_void	hmac_sta_csa_start_timer (hmac_vap_stru *hmac_vap, const oal_ieee80211_channel_sw_ie *const csa_info)
OSAL_STATIC osal_void	hmac_sta_csa_fsm_start_get_csa_ie (hmac_vap_stru *hmac_vap, const oal_ieee80211_channel_sw_ie *const csa_info)
OSAL_STATIC osal_u32	hmac_sta_csa_stop_timeout_fn (osal_void *arg)
OSAL_STATIC osal_u32	hmac_sta_csa_fsm_scan_end (hmac_vap_stru *hmac_vap)
OSAL_STATIC osal_void	hmac_sta_csa_fsm_attach (hmac_vap_stru *hmac_vap)
OSAL_STATIC osal_void	hmac_sta_csa_fsm_detach (hmac_vap_stru *hmac_vap)
OAL_STATIC osal_void	hmac_csa_adjust_bandwidth_sta (hmac_vap_stru *hmac_vap, wlan_channel_bandwidth_enum_uint8 *bandwidth)
OSAL_STATIC osal_u32	hmac_ie_proc_wide_bandwidth_ie (hmac_vap_stru *hmac_vap, const osal_u8 *payload)
OSAL_STATIC osal_u32	hmac_ie_proc_csa_bw_ie (hmac_vap_stru *hmac_vap, osal_u8 *payload, osal_u16 frame_len)
OSAL_STATIC osal_void	hmac_do_ch_switch (hmac_vap_stru *hmac_vap, osal_u8 ch_sw_mode, osal_u8 new_chan, osal_u8 sw_cnt)
OSAL_STATIC osal_void	hmac_ie_proc_ch_switch_ie (hmac_vap_stru *hmac_vap, const osal_u8 *payload, mac_eid_enum_uint8 eid_type)
OSAL_STATIC osal_void	hmac_chan_update_csw_info (hmac_vap_stru *hmac_vap, const osal_u8 *payload, osal_u16 frame_len)
OSAL_STATIC osal_void	hmac_sta_up_rx_ch_switch (hmac_vap_stru *hmac_vap, osal_u8 *frame, osal_u16 len)
OSAL_STATIC osal_void	hmac_sta_up_rx_ext_ch_switch (hmac_vap_stru *hmac_vap, osal_u8 *frame_body, osal_u16 framebody_len)
OSAL_STATIC osal_u32	hmac_scan_check_assoc_ap_channel (hmac_vap_stru *hmac_vap, oal_netbuf_stru *netbuf)
OSAL_STATIC osal_void	hmac_scan_check_assoc_ap_channel_event (hmac_vap_stru *hmac_vap, scan_check_assoc_channel_enum_uint8 check_mode, osal_u8 frame_channel, osal_u8 channel_number)
OSAL_STATIC osal_bool	hmac_csa_sta_vap_add (osal_void *notify_data)
OSAL_STATIC osal_bool	hmac_csa_sta_vap_del (osal_void *notify_data)
OSAL_STATIC osal_bool	hmac_csa_sta_users_add (osal_void *notify_data)
OSAL_STATIC osal_bool	hmac_csa_sta_users_del (osal_void *notify_data)
OSAL_STATIC osal_bool	hmac_csa_sta_tbtt_event (osal_void *notify_data)
OSAL_STATIC osal_bool	hmac_csa_sta_vap_state_change (osal_void *notify_data)
OSAL_STATIC osal_void	hmac_csa_sta_rx_beacon_probe_rsp (oal_netbuf_stru *netbuf, hmac_vap_stru *hmac_vap)
OSAL_STATIC osal_u32	hmac_csa_sta_rx_mgmt (oal_netbuf_stru **netbuf, hmac_vap_stru *hmac_vap)
OSAL_STATIC osal_bool	hmac_csa_sta_scan_end (osal_void *notify_data)
OSAL_STATIC osal_bool	hmac_csa_sta_roam_active (osal_void *notify_data)
osal_u32	hmac_csa_sta_init (osal_void)
osal_void	hmac_csa_sta_deinit (osal_void)

变量
hmac_vap_csa_stru *	g_csa_sta_vapinfo [WLAN_VAP_MAX_NUM_PER_DEVICE_LIMIT]
const oal_fsm_state_info	g_sta_csa_fsm_info []
hmac_netbuf_hook_stru	g_csa_sta_netbuf_hook

宏定义说明

THIS_FILE_ID

#define THIS_FILE_ID   DIAG_FILE_ID_WIFI_HOST_HMAC_CSA_STA_C

THIS_MOD_ID

#define THIS_MOD_ID   DIAG_MOD_ID_WIFI_HOST

函数说明

hmac_chan_update_csw_info()

OSAL_STATIC osal_void hmac_chan_update_csw_info	(	hmac_vap_stru *	hmac_vap,
		const osal_u8 *	payload,
		osal_u16	frame_len
	)

hmac_csa_adjust_bandwidth_sta()

OAL_STATIC osal_void hmac_csa_adjust_bandwidth_sta	(	hmac_vap_stru *	hmac_vap,
		wlan_channel_bandwidth_enum_uint8 *	bandwidth
	)

hmac_csa_sta_deinit()

osal_void hmac_csa_sta_deinit

(

osal_void

)

hmac_csa_sta_init()

osal_u32 hmac_csa_sta_init

(

osal_void

)

hmac_csa_sta_roam_active()

OSAL_STATIC osal_bool hmac_csa_sta_roam_active

(

osal_void *

notify_data

)

hmac_csa_sta_rx_beacon_probe_rsp()

OSAL_STATIC osal_void hmac_csa_sta_rx_beacon_probe_rsp	(	oal_netbuf_stru *	netbuf,
		hmac_vap_stru *	hmac_vap
	)

hmac_csa_sta_rx_mgmt()

OSAL_STATIC osal_u32 hmac_csa_sta_rx_mgmt	(	oal_netbuf_stru **	netbuf,
		hmac_vap_stru *	hmac_vap
	)

hmac_csa_sta_scan_end()

OSAL_STATIC osal_bool hmac_csa_sta_scan_end

(

osal_void *

notify_data

)

hmac_csa_sta_switch_channel()

OSAL_STATIC osal_void hmac_csa_sta_switch_channel

(

hmac_vap_stru *

hmac_vap

)

hmac_csa_sta_tbtt_event()

OSAL_STATIC osal_bool hmac_csa_sta_tbtt_event

(

osal_void *

notify_data

)

hmac_csa_sta_users_add()

OSAL_STATIC osal_bool hmac_csa_sta_users_add

(

osal_void *

notify_data

)

hmac_csa_sta_users_del()

OSAL_STATIC osal_bool hmac_csa_sta_users_del

(

osal_void *

notify_data

)

hmac_csa_sta_vap_add()

OSAL_STATIC osal_bool hmac_csa_sta_vap_add

(

osal_void *

notify_data

)

hmac_csa_sta_vap_del()

OSAL_STATIC osal_bool hmac_csa_sta_vap_del

(

osal_void *

notify_data

)

hmac_csa_sta_vap_state_change()

OSAL_STATIC osal_bool hmac_csa_sta_vap_state_change

(

osal_void *

notify_data

)

hmac_do_ch_switch()

OSAL_STATIC osal_void hmac_do_ch_switch	(	hmac_vap_stru *	hmac_vap,
		osal_u8	ch_sw_mode,
		osal_u8	new_chan,
		osal_u8	sw_cnt
	)

hmac_ie_proc_ch_switch_ie()

OSAL_STATIC osal_void hmac_ie_proc_ch_switch_ie	(	hmac_vap_stru *	hmac_vap,
		const osal_u8 *	payload,
		mac_eid_enum_uint8	eid_type
	)

hmac_ie_proc_csa_bw_ie()

OSAL_STATIC osal_u32 hmac_ie_proc_csa_bw_ie	(	hmac_vap_stru *	hmac_vap,
		osal_u8 *	payload,
		osal_u16	frame_len
	)

hmac_ie_proc_wide_bandwidth_ie()

OSAL_STATIC osal_u32 hmac_ie_proc_wide_bandwidth_ie	(	hmac_vap_stru *	hmac_vap,
		const osal_u8 *	payload
	)

hmac_scan_check_assoc_ap_channel()

OSAL_STATIC osal_u32 hmac_scan_check_assoc_ap_channel	(	hmac_vap_stru *	hmac_vap,
		oal_netbuf_stru *	netbuf
	)

hmac_scan_check_assoc_ap_channel_event()

OSAL_STATIC osal_void hmac_scan_check_assoc_ap_channel_event	(	hmac_vap_stru *	hmac_vap,
		scan_check_assoc_channel_enum_uint8	check_mode,
		osal_u8	frame_channel,
		osal_u8	channel_number
	)

hmac_sta_csa_fsm_attach()

OSAL_STATIC osal_void hmac_sta_csa_fsm_attach

(

hmac_vap_stru *

hmac_vap

)

hmac_sta_csa_fsm_detach()

OSAL_STATIC osal_void hmac_sta_csa_fsm_detach

(

hmac_vap_stru *

hmac_vap

)

hmac_sta_csa_fsm_get_current_state()

OSAL_STATIC osal_u8 hmac_sta_csa_fsm_get_current_state

(

hmac_vap_stru *

hmac_vap

)

hmac_sta_csa_fsm_init_entry()

OSAL_STATIC osal_void hmac_sta_csa_fsm_init_entry

(

osal_void *

ctx

)

hmac_sta_csa_fsm_init_event()

OSAL_STATIC osal_u32 hmac_sta_csa_fsm_init_event	(	osal_void *	ctx,
		osal_u16	event,
		osal_u16	event_data_len,
		osal_void *	event_data
	)

hmac_sta_csa_fsm_invalid_entry()

OSAL_STATIC osal_void hmac_sta_csa_fsm_invalid_entry

(

osal_void *

ctx

)

hmac_sta_csa_fsm_invalid_event()

OSAL_STATIC osal_u32 hmac_sta_csa_fsm_invalid_event	(	osal_void *	ctx,
		osal_u16	event,
		osal_u16	event_data_len,
		osal_void *	event_data
	)

hmac_sta_csa_fsm_is_waiting()

OSAL_STATIC osal_bool hmac_sta_csa_fsm_is_waiting

(

hmac_vap_stru *

hmac_vap

)

hmac_sta_csa_fsm_post_event()

OSAL_STATIC osal_u32 hmac_sta_csa_fsm_post_event	(	hmac_vap_stru *	hmac_vap,
		osal_u16	type,
		osal_u16	datalen,
		osal_u8 *	data
	)

hmac_sta_csa_fsm_scan_end()

OSAL_STATIC osal_u32 hmac_sta_csa_fsm_scan_end

(

hmac_vap_stru *

hmac_vap

)

hmac_sta_csa_fsm_start_event()

OSAL_STATIC osal_u32 hmac_sta_csa_fsm_start_event	(	osal_void *	ctx,
		osal_u16	event,
		osal_u16	event_data_len,
		osal_void *	event_data
	)

hmac_sta_csa_fsm_start_get_csa_ie()

OSAL_STATIC osal_void hmac_sta_csa_fsm_start_get_csa_ie	(	hmac_vap_stru *	hmac_vap,
		const oal_ieee80211_channel_sw_ie *const	csa_info
	)

hmac_sta_csa_fsm_switch_event()

OSAL_STATIC osal_u32 hmac_sta_csa_fsm_switch_event	(	osal_void *	ctx,
		osal_u16	event,
		osal_u16	event_data_len,
		osal_void *	event_data
	)

hmac_sta_csa_fsm_trans_to_state()

OSAL_STATIC osal_void hmac_sta_csa_fsm_trans_to_state	(	hmac_vap_stru *	hmac_vap,
		osal_u8	state
	)

hmac_sta_csa_fsm_wait_event()

OSAL_STATIC osal_u32 hmac_sta_csa_fsm_wait_event	(	osal_void *	ctx,
		osal_u16	event,
		osal_u16	event_data_len,
		osal_void *	event_data
	)

hmac_sta_csa_have_vap_is_in_assoc()

OSAL_STATIC osal_bool hmac_sta_csa_have_vap_is_in_assoc

(

const hmac_vap_stru *

hmac_vap

)

hmac_sta_csa_start_timer()

OSAL_STATIC osal_void hmac_sta_csa_start_timer	(	hmac_vap_stru *	hmac_vap,
		const oal_ieee80211_channel_sw_ie *const	csa_info
	)

hmac_sta_csa_stop_timeout_fn()

OSAL_STATIC osal_u32 hmac_sta_csa_stop_timeout_fn

(

osal_void *

arg

)

hmac_sta_csa_timeout_fn()

OSAL_STATIC osal_u32 hmac_sta_csa_timeout_fn

(

osal_void *

arg

)

hmac_sta_up_rx_ch_switch()

OSAL_STATIC osal_void hmac_sta_up_rx_ch_switch	(	hmac_vap_stru *	hmac_vap,
		osal_u8 *	frame,
		osal_u16	len
	)

hmac_sta_up_rx_ext_ch_switch()

OSAL_STATIC osal_void hmac_sta_up_rx_ext_ch_switch	(	hmac_vap_stru *	hmac_vap,
		osal_u8 *	frame_body,
		osal_u16	framebody_len
	)

hmac_trigger_csa_init_scan_params()

OSAL_STATIC osal_u32 hmac_trigger_csa_init_scan_params	(	const hmac_vap_stru *	hmac_vap,
		mac_scan_req_stru *	scan_params
	)

hmac_trigger_csa_scan()

OSAL_STATIC osal_u32 hmac_trigger_csa_scan

(

hmac_vap_stru *

hmac_vap

)

变量说明

g_csa_sta_netbuf_hook

hmac_netbuf_hook_stru g_csa_sta_netbuf_hook

初始值:

= {
    .hooknum = HMAC_FRAME_MGMT_RX_EVENT_D2H,
    .priority = HMAC_HOOK_PRI_LOW,
    .hook_func = hmac_csa_sta_rx_mgmt,
}

g_csa_sta_vapinfo

hmac_vap_csa_stru* g_csa_sta_vapinfo[WLAN_VAP_MAX_NUM_PER_DEVICE_LIMIT]

初始值:

= {
    OSAL_NULL, OSAL_NULL, OSAL_NULL, OSAL_NULL
}

g_sta_csa_fsm_info

const oal_fsm_state_info g_sta_csa_fsm_info[]
