los_sortlink_pri.h 文件参考

#include "los_typedef.h"
#include "los_list.h"
#include "los_config.h"

los_sortlink_pri.h 的引用(Include)关系图:

此图展示该文件直接或间接的被哪些文件引用了:

浏览源代码.

结构体
struct	SortLinkList
struct	SortLinkAttribute

宏定义
#define	OS_TSK_HIGH_BITS   3U
#define	OS_TSK_LOW_BITS   (32U - OS_TSK_HIGH_BITS)
#define	OS_TSK_SORTLINK_LOGLEN   OS_TSK_HIGH_BITS
#define	OS_TSK_SORTLINK_LEN   (1U << OS_TSK_SORTLINK_LOGLEN)
#define	OS_TSK_SORTLINK_MASK   (OS_TSK_SORTLINK_LEN - 1U)
#define	OS_TSK_MAX_ROLLNUM   (0xFFFFFFFFU - OS_TSK_SORTLINK_LEN)
#define	OS_TSK_HIGH_BITS_MASK   (OS_TSK_SORTLINK_MASK << OS_TSK_LOW_BITS)
#define	OS_TSK_LOW_BITS_MASK   (~OS_TSK_HIGH_BITS_MASK)
#define	SORTLINK_CURSOR_UPDATE(CURSOR)   ((CURSOR) = ((CURSOR) + 1) & OS_TSK_SORTLINK_MASK)
#define	SORTLINK_LISTOBJ_GET(LISTOBJ, SORTLINK)   ((LISTOBJ) = (SORTLINK)->sortLink + (SORTLINK)->cursor)
#define	EVALUATE_L(NUM, VALUE)   ((NUM) = (((NUM) & OS_TSK_HIGH_BITS_MASK) | (VALUE)))
#define	EVALUATE_H(NUM, VALUE)   ((NUM) = (((NUM) & OS_TSK_LOW_BITS_MASK) | ((VALUE) << OS_TSK_LOW_BITS)))
#define	ROLLNUM_SUB(NUM1, NUM2)
#define	ROLLNUM_ADD(NUM1, NUM2)
#define	ROLLNUM_DEC(NUM)   ((NUM) = ((NUM) - 1))
#define	ROLLNUM(NUM)   ((NUM) & OS_TSK_LOW_BITS_MASK)
#define	SORT_INDEX(NUM)   ((NUM) >> OS_TSK_LOW_BITS)
#define	SET_SORTLIST_VALUE(sortList, value)   (((SortLinkList *)(sortList))->idxRollNum = (value))

函数
VOID	OsSortLinkInit (SortLinkAttribute *sortLinkHeader, LOS_DL_LIST *list)
VOID	OsAdd2SortLink (const SortLinkAttribute *sortLinkHeader, SortLinkList *sortList)
VOID	OsDeleteSortLink (const SortLinkAttribute *sortLinkHeader, SortLinkList *sortList)
UINT32	OsSortLinkGetNextExpireTime (const SortLinkAttribute *sortLinkHeader)
UINT32	OsSortLinkGetTargetExpireTime (const SortLinkAttribute *sortLinkHeader, const SortLinkList *targetSortList)
VOID	OsSortLinkUpdateExpireTime (UINT32 sleepTicks, SortLinkAttribute *sortLinkHeader)
UINT32	OsSortLinkGetNextTaskExpireTime (UINT32 *taskId, UINTPTR *handler)
UINT32	OsSortLinkGetNextSwtmrExpireTime (UINT32 *swtmrId, UINTPTR *handler)

宏定义说明

EVALUATE_H

#define EVALUATE_H	(		NUM,
			VALUE
	)		((NUM) = (((NUM) & OS_TSK_LOW_BITS_MASK) | ((VALUE) << OS_TSK_LOW_BITS)))

EVALUATE_L

#define EVALUATE_L	(		NUM,
			VALUE
	)		((NUM) = (((NUM) & OS_TSK_HIGH_BITS_MASK) | (VALUE)))

OS_TSK_HIGH_BITS

#define OS_TSK_HIGH_BITS   3U

OS_TSK_HIGH_BITS_MASK

#define OS_TSK_HIGH_BITS_MASK   (OS_TSK_SORTLINK_MASK << OS_TSK_LOW_BITS)

OS_TSK_LOW_BITS

#define OS_TSK_LOW_BITS   (32U - OS_TSK_HIGH_BITS)

OS_TSK_LOW_BITS_MASK

#define OS_TSK_LOW_BITS_MASK   (~OS_TSK_HIGH_BITS_MASK)

OS_TSK_MAX_ROLLNUM

#define OS_TSK_MAX_ROLLNUM   (0xFFFFFFFFU - OS_TSK_SORTLINK_LEN)

OS_TSK_SORTLINK_LEN

#define OS_TSK_SORTLINK_LEN   (1U << OS_TSK_SORTLINK_LOGLEN)

OS_TSK_SORTLINK_LOGLEN

#define OS_TSK_SORTLINK_LOGLEN   OS_TSK_HIGH_BITS

OS_TSK_SORTLINK_MASK

#define OS_TSK_SORTLINK_MASK   (OS_TSK_SORTLINK_LEN - 1U)

ROLLNUM

#define ROLLNUM

(

NUM

)

((NUM) & OS_TSK_LOW_BITS_MASK)

ROLLNUM_ADD

#define ROLLNUM_ADD	(		NUM1,
			NUM2
	)

值:

                                                ((NUM1) = (((NUM1) & OS_TSK_HIGH_BITS_MASK) | \
                                                (ROLLNUM(NUM1) + ROLLNUM(NUM2))))

ROLLNUM_DEC

#define ROLLNUM_DEC

(

NUM

)

((NUM) = ((NUM) - 1))

ROLLNUM_SUB

#define ROLLNUM_SUB	(		NUM1,
			NUM2
	)

值:

                                                ((NUM1) = (((NUM1) & OS_TSK_HIGH_BITS_MASK) | \
                                                (ROLLNUM(NUM1) - ROLLNUM(NUM2))))

SET_SORTLIST_VALUE

#define SET_SORTLIST_VALUE	(		sortList,
			value
	)		(((SortLinkList *)(sortList))->idxRollNum = (value))

SORT_INDEX

#define SORT_INDEX

(

NUM

)

((NUM) >> OS_TSK_LOW_BITS)

SORTLINK_CURSOR_UPDATE

#define SORTLINK_CURSOR_UPDATE

(

CURSOR

)

((CURSOR) = ((CURSOR) + 1) & OS_TSK_SORTLINK_MASK)

SORTLINK_LISTOBJ_GET

#define SORTLINK_LISTOBJ_GET	(		LISTOBJ,
			SORTLINK
	)		((LISTOBJ) = (SORTLINK)->sortLink + (SORTLINK)->cursor)

函数说明

OsAdd2SortLink()

VOID OsAdd2SortLink ( const SortLinkAttribute *  sortLinkHeader, SortLinkList *  sortList  )

extern

OsDeleteSortLink()

VOID OsDeleteSortLink ( const SortLinkAttribute *  sortLinkHeader, SortLinkList *  sortList  )

extern

OsSortLinkGetNextExpireTime()

UINT32 OsSortLinkGetNextExpireTime ( const SortLinkAttribute *  sortLinkHeader )

extern

OsSortLinkGetNextSwtmrExpireTime()

UINT32 OsSortLinkGetNextSwtmrExpireTime ( UINT32 *  swtmrId, UINTPTR *  handler  )

extern

OsSortLinkGetNextTaskExpireTime()

UINT32 OsSortLinkGetNextTaskExpireTime ( UINT32 *  taskId, UINTPTR *  handler  )

extern

OsSortLinkGetTargetExpireTime()

UINT32 OsSortLinkGetTargetExpireTime ( const SortLinkAttribute *  sortLinkHeader, const SortLinkList *  targetSortList  )

extern

OsSortLinkInit()

VOID OsSortLinkInit ( SortLinkAttribute *  sortLinkHeader, LOS_DL_LIST *  list  )

extern

OsSortLinkUpdateExpireTime()

VOID OsSortLinkUpdateExpireTime ( UINT32  sleepTicks, SortLinkAttribute *  sortLinkHeader  )

extern
