#include "mac_vap_ext.h"
#include "oal_ext_if.h"
#include "oam_ext_if.h"
#include "msg_wow_rom.h"

soc_wifi_driver_api.h 的引用(Include)关系图:

结构体
struct	mac_cfg_linkloss_threshold

struct	mac_cfg_power_ref

struct	mac_cfg_gain_db_2g_band

struct	mac_cfg_pm_param

struct	mac_cfg_psm_offset

struct	mac_cfg_retry_param_stru

struct	mac_cfg_send_action_param_stru

struct	mac_cfg_tx_nulldata_stru

struct	mac_cfg_set_rx_pn_stru

struct	mac_cfg_set_soft_retry_stru

struct	mac_cfg_cal_bpower

struct	mac_cfg_cal_rpower

类型定义
typedef td_u8	mac_cfg_tpc_mode_enum_uint8

typedef td_u8	mac_cfg_rts_mode_enum_uint8

typedef td_u8	mac_cfg_retry_type_enum_uint8

typedef td_u8	mac_cfg_psm_offset_type_uint8

typedef osal_u8	mac_alg_intrf_mode_enum_uint8

typedef osal_u8	alg_rts_mode_enum_uint8

typedef void(*	wifi_csi_data_cb) (unsigned char *csi_data, int len)

typedef mac_cfg_add_user_param_stru	mac_cfg_del_user_param_stru

枚举
enum	mac_cfg_tpc_mode_enum { MAC_API_TPC_OFF_MODE = 0 , MAC_API_TPC_PROMOTE_MODE = 1 , MAC_API_TPC_AUTO_MODE = 2 , MAC_API_TPC_MODE_BUTT }

enum	mac_cfg_rts_mode_enum { MAC_API_RTS_AUTO_MODE = 0 , MAC_API_RTS_THRES_MODE = 1 , MAC_API_RTS_OFF_MODE = 2 , MAC_API_RTS_MODE_BUTT }

enum	mac_cfg_retry_type_enum { MAC_CFG_RETRY_DATA = 0 , MAC_CFG_RETRY_MGMT = 1 , MAC_CFG_RETRY_TIMEOUT = 2 , MAC_CFG_RETRY_TYPE_BUTT }

enum	mac_cfg_psm_offset_type { MAC_PSM_OFFSET_TBTT , MAC_PSM_OFFSET_EXT_TBTT , MAC_PSM_OFFSET_BCN_TIMEOUT }

enum	mac_alg_intrf_mode_enum { MAC_ALG_INTRF_EDCA = 0 , MAC_ALG_INTRF_VO = 1 , MAC_ALG_INTRF_CCA = 2 , MAC_ALG_INTRF_11B = 3 , MAC_ALG_INTRF_11N = 4 , MAC_ALG_INTRF_LONG_RANGE = 5 , MAC_ALG_INTRF_NO_11B = 6 , MAC_ALG_INTRF_BUTT }

enum	alg_rts_mode_enum { ALG_RTS_MODE_ALL_ENABLE = 0 , ALG_RTS_MODE_ALL_DISABLE = 1 , ALG_RTS_MODE_RATE0_DYNAMIC = 2 , ALG_RTS_MODE_RATE0_DISABLE = 3 , ALG_RTS_MODE_THRESHOLD = 4 , ALG_RTS_MODE_BUTT }

函数
td_void	wal_csi_register_data_report_cb (wifi_csi_data_cb data_cb)

td_s32	wal_csi_data_report (hmac_vap_stru hmac_vap, frw_msg msg)

td_s32	wal_psd_data_report (hmac_vap_stru hmac_vap, frw_msg msg)

td_s32	uapi_set_gpio_val (td_s8 *param)

td_u8	uapi_get_custom_cali_done_etc (osal_void)
