los_hwi_pri.h 文件参考

#include "los_hwi.h"
#include "los_spinlock.h"

los_hwi_pri.h 的引用(Include)关系图:

此图展示该文件直接或间接的被哪些文件引用了:

浏览源代码.

结构体
struct	tagHwiHandleForm
struct	HwiStatus
struct	HwiControllerOps
struct	tagBhwork

宏定义
#define	HWI_LOCK(state)   LOS_SpinLockSave(NULL, &(state))
#define	HWI_UNLOCK(state)   LOS_SpinUnlockRestore(NULL, (state))
#define	OS_HWI_INVALID_IRQ   0xFFFFFFFF
#define	OS_HWI_UNSUPPORTED_STATUS   0xFFFFFFFF
#define	HWI_IS_REGISTED(num)   OsIntIsRegisted(num)

类型定义
typedef struct tagHwiHandleForm	HwiHandleInfo
typedef struct tagBhwork	HwiBhworkItem

函数
UINT32	OsHwiInit (VOID)
size_t	OsIrqNestingCntGet (VOID)
VOID	OsIrqNestingCntSet (size_t val)
VOID	OsIntEntry (VOID)
STATIC INLINE HwiHandleInfo *	OsGetHwiForm (UINT32 hwiNum)
STATIC INLINE UINT32	OsIntNumGet (VOID)
STATIC INLINE BOOL	OsIntIsRegisted (UINT32 num)
STATIC INLINE HWI_ARG_T	OsIntGetPara (UINT32 num)
STATIC INLINE CHAR *	OsIntVersionGet (VOID)
VOID	OsIntHandle (UINT32 hwiNum, HwiHandleInfo *handleForm)
STATIC INLINE VOID	OsHwiControllerReg (const HwiControllerOps *ops)

变量
const HwiControllerOps *	g_hwiOps

宏定义说明

HWI_IS_REGISTED

#define HWI_IS_REGISTED

(

num

)

OsIntIsRegisted(num)

HWI_LOCK

#define HWI_LOCK

(

state

)

LOS_SpinLockSave(NULL, &(state))

HWI_UNLOCK

#define HWI_UNLOCK

(

state

)

LOS_SpinUnlockRestore(NULL, (state))

OS_HWI_INVALID_IRQ

#define OS_HWI_INVALID_IRQ   0xFFFFFFFF

OS_HWI_UNSUPPORTED_STATUS

#define OS_HWI_UNSUPPORTED_STATUS   0xFFFFFFFF

This represents that the status of interrupt is not supported.

类型定义说明

HwiBhworkItem

typedef struct tagBhwork HwiBhworkItem

HwiHandleInfo

typedef struct tagHwiHandleForm HwiHandleInfo

函数说明

OsGetHwiForm()

STATIC INLINE HwiHandleInfo * OsGetHwiForm

(

UINT32

hwiNum

)

OsHwiControllerReg()

STATIC INLINE VOID OsHwiControllerReg

(

const HwiControllerOps *

ops

)

When interrupting the controller driver initialization, controller-related operations need to be implemented and registered;Because the function pointer is not judged in the abstraction layer, all function members defined in HwiControllerOps need to be registered. If this function is not supported, you can call the LOS_Panic interface in the implementation of the stub function to report an error in time.

OsHwiInit()

UINT32 OsHwiInit ( VOID  )

extern

OsIntEntry()

VOID OsIntEntry ( VOID  )

extern

OS Interrupt entry, called by assembly code in dispatch.S. The unified entrance of external interrupt is taken over by the kernel. The handleIrq hook function MUST be registered in the interrupt controller driver layer, otherwise it will not respond. eg: Used for arm(cortex-a/r)/arm64.

OsIntGetPara()

STATIC INLINE HWI_ARG_T OsIntGetPara

(

UINT32

num

)

OsIntHandle()

VOID OsIntHandle ( UINT32  hwiNum, HwiHandleInfo *  handleForm  )

extern

If the interrupt is in the scenario where the kernel does not take over, the interrupt controller driver layer realizes the general entry ISR and passes the hwiNum and handleForm to this interface. eg: Used for arm(cortex-m),xtensa,riscv.

OsIntIsRegisted()

STATIC INLINE BOOL OsIntIsRegisted

(

UINT32

num

)

OsIntNumGet()

STATIC INLINE UINT32 OsIntNumGet

(

VOID

)

OsIntVersionGet()

STATIC INLINE CHAR * OsIntVersionGet

(

VOID

)

OsIrqNestingCntGet()

size_t OsIrqNestingCntGet ( VOID  )

extern

OsIrqNestingCntSet()

VOID OsIrqNestingCntSet ( size_t  val )

extern

变量说明

g_hwiOps

const HwiControllerOps* g_hwiOps

extern
